| Weight | 19 kg |
|---|---|
| MOTOR | 550W/220V/50Hz |
| SPINDLE SPEED (rpm) | 2800 |
| CHISEL CAPACITY (mm) | 6.35-12.70 |
| MAX. MORTISING DEPTH (mm) | 76 |
| MAX. DISTANCE SPINDLE to FENCE (mm) | 65 |
| MAX. DISTANCE CHISEL to TABLE (mm) | 140 |
| CHUCK CAPACITY (mm) | 13 |
| BUSHING SIZE (mm) | 19.05 |
| TABLE SIZE (mm) | 210 X 130 |
| BASE SIZE (mm) | 310 X 250 |
| HEIGHT (mm) | 800 |
| PACKING DIMENSIONS (cm) | 44 x 31 x 20 + 50 x 38 x 22 |
| WEIGHT (kg) | 19 + 21 |
| MOTOR | 550W/220V/50Hz |
| SPINDLE SPEED (rpm) | 2800 |
| CHISEL CAPACITY (mm) | 6.35-12.70 |
| MAX. MORTISING DEPTH (mm) | 76 |
| MAX. DISTANCE SPINDLE to FENCE (mm) | 65 |
| MAX. DISTANCE CHISEL to TABLE (mm) | 140 |
| CHUCK CAPACITY (mm) | 13 |
| BUSHING SIZE (mm) | 19.05 |
| TABLE SIZE (mm) | 210 X 130 |
| BASE SIZE (mm) | 310 X 250 |
| HEIGHT (mm) | 800 |
| PACKING DIMENSIONS (cm) | 44 x 31 x 20 + 50 x 38 x 22 |
| WEIGHT (kg) | 19 + 21 |
B2B procurement orders require a formal quotation. Contact our sales engineering team for pricing, tax, and delivery.
