| Weight | 170 kg |
|---|---|
| DIAMETER OF BORING & HONING HOLE (mm) | Ø 39-72 |
| MAX. BORING & HONING DEPTH (mm) | 160 |
| # SPINDLE SPEED | 1 |
| BORING SPINDLE ROTATINAL SPEED (RPM) | 480 |
| BORING SPINDLE FEED (mm/r) | 0.09 |
| MAX. PENETRATION DEPTH BORING TOOL (mm) | 0.3 |
| HONING SPINDLE ROTATIONAL SPEED (RPM) | 303 |
| HONING SPINDLE MOVING SPEED (m/min) | 6.5 |
| RANGE OF CENTERING DEVICE (mm) | Ø39-46 Ø46-54 Ø54-65 Ø65-72 |
| MOTOR SPECIFICATIONS | 700W/220V/ 1440RPM |
| PRODUCT DIMENSION (cm) | 67 X 48 X 115 |
| PACKING DIMENSION (cm) | 76 X 56 X 128 |
| GROSS WEIGHT (kg) | 280 |
| NET WEIGHT (kg) | 170 |
| DIAMETER OF BORING & HONING HOLE (mm) | Ø 39-72 |
| MAX. BORING & HONING DEPTH (mm) | 160 |
| # SPINDLE SPEED | 1 |
| BORING SPINDLE ROTATINAL SPEED (RPM) | 480 |
| BORING SPINDLE FEED (mm/r) | 0.09 |
| MAX. PENETRATION DEPTH BORING TOOL (mm) | 0.3 |
| HONING SPINDLE ROTATIONAL SPEED (RPM) | 303 |
| HONING SPINDLE MOVING SPEED (m/min) | 6.5 |
| RANGE OF CENTERING DEVICE (mm) | Ø39-46 Ø46-54 Ø54-65 Ø65-72 |
| MOTOR SPECIFICATIONS | 700W/220V/ 1440RPM |
| PRODUCT DIMENSION (cm) | 67 X 48 X 115 |
| PACKING DIMENSION (cm) | 76 X 56 X 128 |
| GROSS WEIGHT (kg) | 280 |
| NET WEIGHT (kg) | 170 |
B2B procurement orders require a formal quotation. Contact our sales engineering team for pricing, tax, and delivery.
