| VOLTAGE | AC110-220V 50/60 Hz |
|---|---|
| MOTOR POWER (W) | 140 |
| PRESSURE GAUGE RANGE | 0-16bar (0-220psi) |
| WORKING PRESSURE | ≤6bar (0-87psi) |
| OUTLET PIPE LENGTH (m) | 2.5 |
| INLET PIPE LENGTH (m) | 2.5 |
| DISCHARGE PIPE LENGTH (m) | 1.5 |
| PRECISION FILTER ELEMENT (µm) | 5 |
| VOL. OIL TANK (L) | 25 |
| PRECISE GRAVITY SENSOR (L) | ±0.1 |
| MAX. OIL REPLACING SPEED (L/min) | 3 |
| PRODUCT DIMENSION (mm) | 510 X 540 X 1075 |
| PACKING DIMENSION (mm) | 685 X 435 X 1180 |
| VOLTAGE | AC110-220V 50/60 Hz |
| MOTOR POWER (W) | 140 |
| PRESSURE GAUGE RANGE | 0-16bar (0-220psi) |
| WORKING PRESSURE | ≤6bar (0-87psi) |
| OUTLET PIPE LENGTH (m) | 2.5 |
| INLET PIPE LENGTH (m) | 2.5 |
| DISCHARGE PIPE LENGTH (m) | 1.5 |
| PRECISION FILTER ELEMENT (µm) | 5 |
| VOL. OIL TANK (L) | 25 |
| PRECISE GRAVITY SENSOR (L) | ±0.1 |
| MAX. OIL REPLACING SPEED (L/min) | 3 |
| PRODUCT DIMENSION (mm) | 510 X 540 X 1075 |
| PACKING DIMENSION (mm) | 685 X 435 X 1180 |
B2B procurement orders require a formal quotation. Contact our sales engineering team for pricing, tax, and delivery.
